Tracer Loop Layout (FM-2L-153)
Tracer Loop Layout (FM-2L-153)
Pictured in Satin Brass. View our finish library.
We’ve done the designing for you! Each of our Curated Layouts have been carefully crafted to work with varying ceiling areas and heights. The dimensions for this layout are as follows:
Area on Ceiling: 68in x 68in
Maximum Drop: 40in
This layout is recommended for ceiling heights of 10ft - 12ft
but may work in other areas depending on site conditions. If you would like to make modifications to this layout or have any other questions, please view our Custom Tracer Loop page or email us at info@lukelampco.com.
The ceiling plane shown in the images is not included; each loop mounts individually to the ceiling as explained in the installation instructions below.
____________________________________________________
Want to feel the materials yourself? Rope and finish samples are available upon request. Click here to read more.
Our fixtures are low voltage (24VDC) and need to be installed with the appropriate drivers, which we include. Read about our driver options here.
8–10 week leadtime with complimentary global shipping.
